CELASCHI
PROGRESS 30
Automatic squaring tenoner
Code: 3021
Machinery available through Direct Negotiation. info What is it about?
restore Production year: 2006 error_outline Status: Good
domain Availability: Direct negotiation check_circle EC legislation: Compliant
Production year:
2006
Status:
Good
Availability:
Direct negotiation
EC legislation:
Compliant
Description
Automatic squaring tenoner
CELASCHI PROGRESS 30
This automatic squaring tenoner with manual loading and unloading is designed for processing solid wood, chipboard, fiberboard, and plywood, as well as materials covered with plastic laminates and/or edgebanding.
The machine is designed to process workpieces with the following dimensions:
Length: min. 210 mm - max. 3000 mm
Width: min. 210 mm - max. 3000 mm
Thickness: min. 10 mm - max. 80 mm
Feed speed 4/30 m/min adjustable via inverter
Motor 1
Roughing cutter + hardware milling
Direction of rotation 1 SERCA (counterfeed rotation)
Shaft d. 50 mm, L. 303 mm - Power 9.2 kW - 3400 rpm 50Hz - 6000 rpm 100Hz - Tool diameter 220 - 240 mm
2 Multi-cutter motors
Direction of rotation: 1 SERCA (counterfeed rotation)
Shaft d. 50 mm, L. 500 mm - Power 9.2 kW - 3500 rpm 50Hz - 5400 rpm 100Hz - Tool diameter 220 - 240 mm
3 Multi-cutter motors
Direction of rotation: 1 SERFA (feed rotation)
Shaft d. 50 mm, L. 500 mm - Power 9.2 kW - 3500 rpm 50Hz - 5400 rpm 100Hz - Tool diameter 220 - 240 mm
Technical details
Generals
Sizes*
4720 x 4230 x 2600 mm
Weight*
2500 kg
Total kW*
40
*Shown values may vary depending on the configuration of the machine.
