FELDER - FORMAT4
profit H80 21.31 TPA
Nesting Work Center
Code: 1576
restore Production year: 2021 error_outline Status: Good
domain Availability: In stock check_circle EC legislation: Compliant
Controlled axes number:
3
Description
Nesting Work Center
FELDER – FORMAT4 profit H80 21.31 TPA
Phenolic resin nesting table system with series grooves for inserting templates and clamping a wide variety of materials. The grooves are suitable for inserting a rubber sealing cord, included in the initial supply.
Machine Composition:
Automatic centralized lubrication
UPS - Computer power supply safety system
Automatic Z-axis tool length measurement system
Enclosed cable management along the X and Y axes
Portable terminal for remote axis control
Optical machine status indicator
Grid table with two continuous stops at the front and back, as well as a front stop on the left and right
Stop cylinder monitoring - 2 rows of stops
Central extraction hood
Ejection unit including motorized height adjustment and table extraction system
Retractable tool magazine including hood
Provision for an additional 250 m3/h vacuum pump
DH 16 4H 2S drilling head; with 12 vertical and 4 horizontal spindles; 2 slot saws: 1 in the X-direction and 1 in the Y-direction
0-360° C-axis setup
Grid table with 30 x 30 mm grid
Software:
3D simulator with collision checking for Woodflash at the external workstation
F4Nest Basic
F4Nest Basic to Rectangle Upgrade
F4Nest Rectangle to Freeform Upgrade
F4Nest Excel Import Module
Technical details
Effective working
Effective X
3090 mm
Eeffective Y
2100 mm
Effective Z
85 mm
Details
Heads number
1
Controlled axes number
3
Main motor power
10 kW
Mils connection drive motor
HSK 63F
Security
Photocels
Vacuum pump
2 x 250 mc/h
Software/C.N.
Software
WOOD FLASH
Generals
Sizes*
5400x3500x2300 mm
Weight*
3500 kg
Total kW*
25
*Shown values may vary depending on the configuration of the machine.
